Visit our Showroom for Purchase


Cart type
Product Specifications

Controller: FJ 48V-350A-G1 AC Controller

Battery Pack: KEY POWER 48V 104Ah Lithium Battery System

Traction Motor: 48V 5kW AC Induction Motor

On-board Charger (OBC): Smart On-Board Charger - 48V/25A,Charging time <8 hours

DC-DC Converter: Non-Isolated DC-DC Converter 48V/12V-300W

Windshield: Acrylic organic glass

Seating System: Standard Seats with 2 point seatbelt

Floor Mat: Anti-Slip Flooring

Body: Automotive-Grade PP Injection Molding

Side Mirrors: LEFT&RIGHT Manually Adjustable Foldable Side Mirrors without Indicator light

Lighting & Warning Signals: LED Lighting System:((Low Beam、High Beam、Turn Signal、Position Lamp)/LED Rear light:(Stop Lamp、Tail Lamp、Tail Lamp)Horn、Backup Alarm

Instrument Panel: Injection-Molded Dashboard Assembly,Round LCD EV Instrument Cluster、Ignition Switch、Multi-Function Steering Column Switch 、Gear Selector、Hazard Light Switch、Cup Holders、12V Power Outlet、Digital Clock、USB-A&USB-C

Steering System: Recirculating Ball & Rack Steering with Automatic Backlash Compensation

Service Brake System: Dual-Circuit Hydraulic Disc Brakes (X-Split Configuration)

Parking Brake: Electromagnetic Parking Brake (EPB)

Front Suspension: Double Wishbone Independent Suspension with Coil Springs

Rear Suspension: Final Drive Ratio 12.31 (with Disc Brakes & EPB): Trailing Arm + Coil Spring Suspension

Top Speed (km/h): 25

Ground Clearance (mm):  100

Hill Hold Ability: 20

1. Rearview Mirror with Integrated Turn Signal.
2. Sand bottles.
3. Ball Washer.
4. Cooler.
5. Aluminum Alloy Wheels.

Product Brochure

View Product Brochure


This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.


Don't take our word for it

Smooth and Comfortable Ride

Abdulla Saeed

UAE, Dubai

★★★★★

Clean Design and Practical Features

Mohammed Ahmed

UAE, Dubai

★★★★★

Reliable Electric Performance

Rashid Mohammed

UAE, Abu Dhabi

Golf Cart

FAQs

It uses a KEY POWER 48V 104Ah lithium battery system.

The cart includes a smart on-board charger with a charging time of less than 8 hours.

The top speed is 25 km/h.

Yes. It includes standard seats with 2-point seatbelts, hydraulic disc brakes, an electromagnetic parking brake, LED lighting, side mirrors, horn, and backup alarm.
